Navigation: Home > Products > Grinder Series

30B High Effective Grinder(set)

Product Name：30B High Effective Grinder(set)

Keywords：High Effective Grinder(set),High Effective Grinder
Overview：The machine (set) is extensively used in pharmaceutical, chemical, food and pesticide industries for pulverizing dry brittle materials .

Description

General Descriptions
　　The machine (set) is extensively used in pharmaceutical, chemical, food and pesticide industries for pulverizing dry brittle materials .


Technical Parameter
Spec unit 20B/20B Set 30B/30B Set 40B/40B Set 60B/60B Set
productive capacity kg/h 60-150 100-300 160-800 500-1500
speed of main shaft r/min 4500 3800 3400 2800
feeding granule size mm 6 10 12 15
finesee of pulverization mesh 60-150 60-120 60-120 60-120
grinding motor power kw 4 5.5 11 15
fan power kw 1.5 1.5 1.5 2.2
weight kg 250 320 550 680
overall dimension（L×W×H） mm 550×600×1250 600×700×1450 800×900×1550 1000×900×1680
overall dimension （set）（L×W×H） mm 1100×600×1650 1200×650×1650 1350×700×1700 1550×1000×1750
